PC BACKLIT PANEL

The PC Backlit Panel is a state-of-the-art lighting solution designed to provide bright, even illumination with a sleek, modern aesthetic. These panels are made using polycarbonate (PC), a durable and lightweight material known for its high impact resistance and excellent light-diffusion properties. Unlike edge-lit panels, which emit light from the sides, PC Backlit Panels use a design where the LEDs are positioned directly behind the panel, allowing for more uniform lighting distribution. This makes them an ideal choice for various residential, commercial, and industrial applications.

  • Backlit Design : In a backlit panel, the light source (LEDs) is positioned directly behind the polycarbonate diffuser, allowing for more consistent light distribution across the entire surface. This design eliminates dark spots or uneven lighting often found in edge-lit panels, ensuring a smooth and uniform brightness.

  • Polycarbonate (PC) Material : The use of polycarbonate ensures the panel is durable and impact-resistant, offering long-lasting performance even in high-traffic or industrial environments. The PC material is also known for its excellent light diffusion, which helps spread light evenly across the panel’s surface.

  • Energy Efficiency : PC Backlit Panels use energy-efficient LED technology, which reduces power consumption compared to traditional fluorescent or incandescent lighting. This leads to significant energy savings and a lower environmental footprint. LEDs also have a longer lifespan, which reduces maintenance costs.

  • Long Lifespan : With the combination of durable PC material and long-lasting LED technology, PC Backlit Panels offer a long operational life, reducing the need for frequent replacements. This makes them a cost-effective solution in the long run.

Prodcut Code Series Wattage Length / Dia (mm) Breadth (mm) Height (mm) Cut Out (mm) Surface Ring
GGRDL 5R/SQ RDL Series 6 82 82 35 65 No
GGRDL 8R/SQ RDL/GM Series 8 115 115 35 100 Available
GGRDL 12R/SQ RDL Series 12/15 145 145 35 125 Available
GGRDL 15R/SQ RDL/GM Series 15 165 165 35 150 Available
GGRDL 22R/SQ RDL Series 22 220 220 35 200 Available
GGDIV 10R DIV Series 10 130 - 40 107 No
Operating Voltage: 100-440VAC IP Rating: IP 20 Power Factory: > 0.95 CRI: > 80 Colour Temp: 6000K/4000K/3000K

The Diverse Uses of PC BACKLIT PANEL

  • Offices : Ideal for office spaces, providing uniform, glare-free lighting that improves productivity and comfort.

  • Retail Spaces : Used in stores and showrooms to create a bright, inviting atmosphere that enhances product visibility.

  • Healthcare and Educational Facilities : Perfect for healthcare settings, offering consistent, eye-friendly lighting that promotes a comfortable environment for patients and staff.

  • Residential Spaces : Suitable for kitchens, living rooms, and hallways where bright, uniform lighting is desired.
